It’s the most powerful and technologically advanced Fusion® marine stereo ever. With audiophile-level components and a built-in amplifier providing twice the power of the predecessor RA770, this system delivers lossless audio performance of unmatched clarity. Plus, its Wi-Fi® connectivity supports seamless AirPlay® audio streaming on your boat.
Features:
- Sleek, modern design features edge-to-edge glass display
- Enjoy premium wi-fi streaming with high-resolution lossless audio
- Built-in class-d amplifier boasts 50% more power output
- See quicker response with 8 times faster digital processing speed¹
- Share onboard audio sources with stereo grouping
- Remotely control your music from compatible devices
Specifications:
- Physical dimensions: (Height 82 mm (3.23")
- Physical dimensions: (Width) 192 mm (7.56")
- Physical dimensions: (Depth) 119.4 mm (4.7")
- Weight: 620 g (1.37 lbs)
- Control Surface Dust/Water Rating (when properly installed): IPX6 and IPX7
- Rear Dust/Water Rating (when properly installed): IPX3
- Operating temperature range: -20 to 70° C
- Current draw (max): 25 A at 14.4 V; 15A at 28.8 V
Networking:
- NMEA 2000® LEN: 2 (65 mA)
- Bluetooth® wireless range: Up to 10 metres (30 ft)
- ANT® wireless range: Up to 10 ft (3 metres)
- Wireless frequencies/protocols: WiFi 2.4Ghz : +12dBm nominal MIMO 2 x 2
Bluetooth®: 2.4 GHz @ +10 dBm nominal
ANT®: 2.4GHz 0dBm nominal
Audio:
- Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD): 40 W x 4
Electrical features:
- Power Input: 10.8 to 32 Vdc
- Compass safe distance: 150 mm (5.9)
Stereo features:
- Display Size: 109 mm (4.3")
- Display type: Capacitive touchscreen colour LCD
- Display resolution: 800 x 480
- Optically bonded display: Yes
Built-in amplifier: Class D (4 O) - Built-in Wi-Fi®: Yes
- Built-in Digital Signal Processing (DSP): Yes (with custom DSP profile setup using Fusion-Link™ app)
- Stereo networking: Yes (wired or wireless)
- Control: Yes (MFD, smart device and Garmin watch)
- Multi-Zone™? technology: 4 zones
- Bluetooth® wireless technology: Yes
- ANT® wireless technology: Yes
- Multi-language interface: Bulgarian, Simplified chinese, Traditional chinese, Croatian, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (BR), Portuguese (PT), Slovenian, Spanish, Swedish, Thai, Turkish
- Software updates: Over-the-air updates via Fusion-Link™ app (when connected to wireless network router) / USB
Sources:
- Supported sources: AM, FM, BLUETOOTH®, Apple AirPlay® 2,HDMI ARC,USB audio,iPhone,iPod,AUX x2
- Supported audio formats (USB): MP3, AAC, M4A, FLAC, WAV
Connections:
- Auxiliary inputs (RCA): 2
- HDMI ARC Ports: 1
- Ethernet ports: 1
- NMEA 2000® ports: 1
- USB 2.0 ports: 1 (USB-C)
- Antenna ports: 2 (1x Motorola (female)
- Speaker connections: 4 (2 zone amplified)
- RCA pre-out (left, right and subwoofer - requires external amplification): 4 zones
- Line out (requires external amplification): 4 (L + R per zone)
- Subwoofer out (requires external amplification): 4 (1 mono output per zone)
